VETUS Twin Coil Calorifier 100 Litre With Fitting Kit And 230V/1500W Element

VETUS marine water heaters or calorifiers, make use of surplus heat
from the engine to provide hot fresh water. They are also fitted
with an electric heating element for use when the engine is not
running. All VETUS calorifiers include sturdy mounting brackets for
safe installation and a complete connection set with pressure
relief valve, plus a 1.5 kW electric heating element.

These conventional calorifiers use a spiral tube to heat the water.
The VETUS twin coil calorifiers are supplied with an extra coil so
the water can be also heated by the on board heating system!
Specifications:

Inner tank	Duplex stainless steel
Outer tank	Stainless steel, AISI 316
Insulation	Polyurethane foam, 50 mm thickness. Supplied with white painted steel outer jacket.
Connection engine coolant	G 1/2
Connection fresh water	G 1/2
Connection heating element	G 1/2
Setting of relief valve fresh water	4 Bar (56 lbs/sq.inch)
Contents of fresh water (litres)	100
Contents of coolant (litres)	0.5
