VETUS FTR470 Cooling Water Strainer For 19.1mm Hose Connections

Easy mounting with 360° rotating wall bracket

The VETUS FTR470 Cooling Water Strainer is
supplied with a rotating stainless steel wall bracket for easy
alignment of the hose connections and clamping it securely in
place. This eliminates the need for back-bolting and dramatically
simplifies the mounting process.

Easy inspection
The cover of the water strainer type FTR470 is transparent,
allowing easy inspection for blockages. It is removable by simply
unscrewing a single central knob.

VETUS FTR470 Cooling Water Strainer Features:

• Rotating stainless steel wall bracket for easy
  alignment
• Transparent cover for easy inspection
• Polypropylene GF housing
• HD Polyethylene filter element
• Polypropylene GF/Polycarbonate cover

VETUS FTR470 Cooling Water Strainer
Specifications:

• Part number: FTR470/19
• Weight : 0.45 kg (1 lb)
• Max. ambient temperature: 75 °C (167°F)
• Max. water temperature: 55 °C (131°F)
• Max. pressure: 0.5 bar (50 kPa, 7 psi)
• Internal diameter: 19.1mm
• Recommended input: 51 L/min

VETUS FTR470 Cooling Water Strainer Installation Instructions
